    Automatic Multifunctional
    macro flash is available

    The ELECTRONIC FLASH MACRO EM-140 DG is designed to work with digital SLR cameras of most popular manufacturers. The EM-140 DG is ideal for photographing subjects in fine detail when the shadowless mode is used and is extremely effective for scientific and medical applications. Dual flash tubes can fire simultaneously or separately. Using only one flash tube creates a shadow which can give a three-dimensional feeling to the subject. The flash features a guide number of14 w/ISO 100.

    Features

    Designed to work with new Digital SLR cameras

    ELECTRONIC FLASH MACRO EM-140 DG is fully dedicated with new TTL flash control systems of all-popular camera manufacturers. Automatic functions of this flashgun deliver outstanding results and creative possibilities.

    Macro Flash Adapter in many different sizes

    Both φ55mm and φ62mm Macro Flash Adapter rings are provided with this flash unit, φ52mm, φ58mm, φ67mm, φ72mm and φ77mm ring adapters can be purchased separately. These Macro Flash Adapter rings make it possible to attach this flashgun to a wide variety of lenses.

    Flash tubes can be switched on or off for creative flash control

    The two flash tubes can fire together or independently for a wide range of lighting variations. When shadowless mode is used, subjects can be photographed in fine detail, this can be done by firing both flashtubes. Using only one flashtube creates a shadow which can give a three-dimensional feeling to the subject.

    Equipped with Exposure Compensation Function

    Exposure compensation function delivers outstanding creative possibilities to precisely reflect your intention. Lighting of the subject can be delicately adjusted and balanced with the background.

    Wireless Flash Function

    A three-dimensional feel can be created with the addition of the EF-610 DG SUPER ,EF-530 DG SUPER or EF-500 DG SUPER flashgun. This separate flash unit can be located wirelessly above or to the side of the subject to create a more three-dimensional feel.
    * Wireless Flash Function is not available with some camera models.

    High Speed Synchro (FP) Flash

    High Speed Synchro allows you to use a shutter speed faster than the camera shutter’s normal synchronization speed.

    Modeling Flash Function

    The Modeling Flash allows for checking shadows and light balance on the subject prior to shooting.

    Specifications

    Specifications

    Power source

    AA Alkaline Battery or AA NiCd Battery or AA Ni-Mh Battery x 4pcs

    Angle of Coverage

    Vertical / Horizontal 80 degrees

    Weight

    430g (without batteries)

    Dimensions (W×H×D) Controller

    76.7mm×136.2mm×82.4mm (3.0×5.4×3.2in.)

    Dimensions (W×H×D) Flash Unit

    126.6mm×128.8mm×30.5mm (5.0×5.1×1.2in.)

    Compatible Cameras

    SA-STTL (SIGMA)

    Product Lineup

    ELECTRONIC FLASH MACRO EM-140 DG

    *SIGMA fp only

    Supplied Accessories

    Case、MACRO FLASH ADAPTER (φ55mm、φ62mm)

    Barcode No.
    00-85126-92264-1

    Support

    ELECTRONIC FLASH MACRO EM-140 DG

    Accessories

    Supplied Accessories

    MACRO FLASH ADAPTER 55mm

    * This image is 65mm

    Barcode No.
    00-85126-92270-2

    MACRO FLASH ADAPTER 62mm

    * This image is 65mm

    Barcode No.
    00-85126-92268-9

    Separately Sold Accessories

    MACRO FLASH ADAPTER 52mm

    * This image is 65mm

    Barcode No.
    00-85126-92298-6

    MACRO FLASH ADAPTER 58mm

    * This image is 65mm

    Barcode No.
    00-85126-92269-6

    MACRO FLASH ADAPTER 65mm

    Barcode No.
    00-85126-93662-4

    MACRO FLASH ADAPTER 67mm

    Barcode No.
    00-85126-92320-4

    MACRO FLASH ADAPTER 72mm

    * This image is 65mm

    Barcode No.
    00-85126-92267-2

    MACRO FLASH ADAPTER 77mm

    * This image is 65mm

    Barcode No.
    00-85126-92266-5
