    Specifications

    fp L

    Format

    Type

    Interchangeable-lens Mirrorless Type Digital Camera

    Memory Media

    SD, SDHC, SDXC memory card (UHS-Ⅱ supported) , Portable SSD (USB 3.0 connection, USB bus power supported)

    Lens Mount

    L-Mount

    Image Sensor

    Type

    35 mm full-frame (36.0 mm x 24.0 mm) Back-illuminated Bayer CMOS sensor

    Camera Effective Pixels / Total Pixels

    Approx. 61 MP / Approx. 62.4 MP

    Aspect Ratio

    3:2

    Color Filter System

    RGB Primary color filter

    Still Image File Format

    Lossless compression RAW(DNG) data 12 bit,14 bit / JPEG(Exif2.3), RAW(DNG)+JPEG:recording is possible

    Image Aspect Ratio

    [21:9] / [16:9] / [3:2] / [A Size (√2:1) ] / [4:3] / [7:6] / [1:1]

    File Size

    RAW

    9.5K:9,520 x 6,328
    6.2K:6,240 x 4,144
    4.8K:4,768 x 3,168
    UHD:3,840 x 2,552
    FHD:1,920 x 1,280

    JPEG

    [21:9]

    9.5K:9,520 x 4,080
    6.2K:6,240 x 2,672
    4.8K:4,768 x 2,040
    UHD:3,840 x 1,648
    FHD:1,920 x 824

    [16:9]

    9.5K:9,520 x 5,352
    6.2K:6,240 x 3,512
    4.8K:4,768 x 2,680
    UHD:3,840 x 2,160
    FHD:1,920 x 1,080

    [3:2]

    9.5K:9,520 x 6,328
    6.2K:6,240 x 4,144
    4.8K:4,768 x 3,168
    UHD:3,840 x 2,552
    FHD:1,920 x 1,280

    [A Size (√2:1) ]

    9.5K:8,944 x 6,328
    6.2K:5,856 x 4,144
    4.8K:4,480 x 3,168
    UHD:3,616 x 2,552
    FHD:1,808 x 1,280

    [4:3]

    9.5K:8,432 x 6,328
    6.2K:5,520 x 4,144
    4.8K:4,224 x 3,168
    UHD:3,408 x 2,552
    FHD:1,696 x 1,280

    [7:6]

    9.5K:7,856 x 6,328
    6.2K:5,152 x 4,144
    4.8K:3,920 x 3,168
    UHD:3,168 x 2,552
    FHD:1,584 x 1,280

    [1:1]

    9.5K:6,328 x 6,328
    6.2K:4,144 x 4,144
    4.8K:3,168 x 3,168
    UHD:2,552 x 2,552
    FHD:1,280 x 1,280

    * When a DC lens is attached, it can be used with a recording pixel count of 6.2K or less.

    Crop

    Equivalent to approx.1.5 to 5 times the focal length of the lens (for 35 mm cameras)

    Color Space

    sRGB, Adobe RGB

    Movie Recording Format

    Camera Internal Record

    Movie Format

    CinemaDNG(8 bit, 10 bit, 12 bit)/ MOV:H.264 (ALL-I, GOP)

    Audio Format

    Linear PCM (2 ch 48 kHz / 16 bit)

    Record Format / Frame rate

    3,840 x 2,160 (UHD 4K) / 23.98 p, 24 p, 25 p, 29.97 p
    1,920 x 1,080 (FHD) / 23.98 p, 24 p, 25 p, 29.97 p, 48 p, 50 p, 59.94 p, 100 p*, 119.88 p*
    * Automatic crop zoom setting is x1.67

    Continuous Shooting Enable Time

    Up to 2 hours

    Cinema DNG Memory Media Limitation

    SD Card (UHS-II) : UHD 8 bit 25 p or less, FHD 12 bit 59.94 p or less
    Portable SSD : UHD 12 bit 29.97 p or less, FHD 12 bit 100 p or less, FHD 8 bit 119.88 p or less

    HDMI External Output

    Movie Format

    4:2:2 8 bit
    12 bit RAW :External recorder record : ATOMOS Ninja V, Blackmagic Video Assist 12G supported

    Audio Format

    Linear PCM (2 ch 48 kHz/16 bit)

    Record Format / Frame Rate

    4,096 x 2,160 (DCI 4K) / 24 p * Only for RAW output
    3,840 x 2,160 (UHD 4K) / 23.98 p, 24 p, 25 p, 29.97 p
    1,920 x 1,080 (FHD) / 23.98 p, 24 p, 25 p, 29.97 p, 48 p, 50 p, 59.94 p, 100 p*, 119.88 p*
    * Automatic crop zoom setting is x1.67

    Focus

    AF System / Focus Mode

    Image plane phase-difference AF + Contrast detection system, Single AF, Continuous AF (with moving object prediction function), Manual Focus

    AF Sensitivity Range / AF Mode

    -5 to 18 EV (F1.4:ISO 100) / Auto, 49-point selection mode, Free Move mode, Face/Eye Detection AF mode, Tracking AF mode

    AF Lock

    Half-press the shutter button, or press the AEL button (setting change required)

    Other Focus Functions

    AF+MF, MF Assist, MF Guide, Focus Peaking, Release Focus Function, AF-ON, Quick AF, Pre-AF, AF during Image Magnification

    Exposure Control

    Metering System

    Evaluative, Spot, Center Weighted Average

    Metering Range

    -5 to 18 EV (50 mm F1.4:ISO 100)

    Still Image Shooting Mode

    (P) Program AE (Program Shift capable), (S) Shutter Speed Priority AE, (A) Aperture Priority AE, (M) Manual

    Movie Shooting Mode

    (P) Program AE, (S) Shutter Angle Priority AE, (A) Aperture Priority AE, (M) Manual

    ISO Sensitivity (Recommended exposure value)

    Base ISO

    [Still]
    ISO 100,400
    [Cine]
    CinemaDNG 12 bit / HDMI RAW:ISO 100, 1250
    MOV / CinemaDNG 10 bit, 8 bit, HDMI 4:2:2 8 bit:ISO 100, 250

    Settable Range

    ISO 100-25600 / Expanded sensitivity ISO 6, 12, 25, 50, 51200, 102400

    Exposure Compensation

    ±5 EV (in 1/3 stop increments) : ±3 EV at movie recording

    AE Lock

    Half-press the shutter button, or press the AEL button (setting change required)

    Exposure Bracket

    3 shots / 5 shots stage exposure 3EV (1/3 Step, Standard→Underexposure→Overexposure) (Sequence changeable)

    Image Stabilization System

    Image Stabilization System(EIS)

    White Balance

    12 types
    ( Auto, Auto[Lighting Source Priority], Daylight, Shade, Overcast, Incandescent, Fluorescent, Flash, Color Temperature[50K steps], Custom 1, Custom 2, Custom 3 )

    Shutter

    Shutter Type

    Electronic shutter

    Shutter Speed

    30 to 1/8,000 sec., Bulb up to 300 sec.

    Self Timer

    2 sec. / 10 sec.

    Drive

    Drive Modes

    Single Capture, Continuous, Self Timer (2sec. / 10sec.), Interval Timer

    Continuous Drive Speed

    High Speed:approx. 10 shots/ sec., Medium Speed:approx. 5 shots/ sec., Low Speed:approx. 3 shots/ sec.

    Number of Recordable Frames

    DNG+J (14 bit) / 9.5K:12 frames, 6.2K:12 frames, 4.8K or less:12 frames
    DNG+J (12 bit) , DNG (14 bit/12 bit) / 9.5K:12 frames, 6.2K:28 frames, 4.8K or less:50 frames
    JPEG / 9.5K:14 frames, 6.2K:35 frames, 4.8K or less:57 frames

    Monitor

    Type / Coverage

    TFT color LCD, Aspect Ratio 3:2, 3.15 type, Approx. 2.1M dots , Electrostatic capacitance system touch panel / Approx. 100%

    Flash (when to use external flash)

    Built-in Flash

    Flash Mode

    S-TTL automatic light control, Manual, Wireless flash, Multi-emission

    Optional Functions

    Red-eye Reduction / Slow Synchronization, Rear Curtain Synchronization

    Flash Exposure Compensation

    Max. ±3 EV in 1/3EV step increments

    Flash Sync. Speed

    Max. 1/15 sec.
    * 1/10 sec. or less at 14 bit RAW

    External Flash Support

    Available when the HOT SHOE UNIT HU-11 (supplied with this product) is mounted. * S-TTL, Wireless support, X-sync.

    Color Mode

    15 types
    (Standard, Vivid, Neutral, Portrait, Landscape, Cinema, Teal and Orange, Sunset Red, Forest Green, Powder Blue, FOV Classic Blue, FOV Classic Yellow, Duotone, Monochrome, Off )

    Director’s Viewfinder

    Supported cameras

    ARRI

    ARRICAM / ARRIFLEX, ALEXA LF/ ALEXA Mini LF, ALEXA SXT, ALEXA Mini, AMIRA, ALEXA65, ALEXA XT

    SONY

    VENICE

    RED

    MONSTRO 8K, HELIUM 8K, DRAGON 6K, EPIC MX 5K, GEMINI 5K, KOMODO 6K

    Frame Guide

    1.33:1, 1.85:1, 2.39:1, Custom 1, Custom 2

    Custom Frame

    Input (Sensor Area / Aspect Ratio) , Offset, Style (4 styles) , Line (1 to 10 px) , Color (White, Black, Red, Yellow, Green, Cyan, Blue, Magenta) , Shading

    Other Functions

    Save / Load Settings via QR code, Screenshot, Webcam, In-camera RAW development, Still image capture from recorded movie files, Cinemagraph, Fill Light, HDR shooting (Still / Cine) , Still image shooting during movie shooting

    Built-in Microphone / Speaker

    Stereo microphone, Monaural speaker

    Display Language

    English / Japanese / German / French / Spanish / Italian / Simplified Chinese / Traditional Chinese / Korean / Russian / Dutch / Polish / Portuguese / Danish / Swedish / Norwegian / Finnish

    Interface

    USB Terminal

    USB3.1 GEN1 Type-C (supports Mass Stroage, Video Class(UVC), Camera Control)

    HDMI Terminal

    Type D(Ver.1.4)

    Remote

    Also used as an external microphone terminal

    Timecode Input

    Also used as an external microphone terminal

    External Microphone Terminal

    Φ3.5 mm stereo mini jack (Plug-in power support)

    Headphone Output Terminal

    Φ3.5 mm stereo mini jack (can be connected when using the dedicated ELECTRONIC VIEWFINDER EVF-11)

    Flash-synchro Terminal

    Dedicated terminal (with HOT SHOE UNIT HU-11 (supplied with this product) mounted)

    Dust and Splash Resistant Structure*

    Provided
    *Although this construction allows the lens to be used in light rain, it is not the same as being waterproof.

    Power

    Power

    Li-ion Battery Pack BP-51
    * Internal battery charge via USB terminal available.
    * USB power supply available.

    Number of Recordable Still Images

    Approx. 240 images

    Minutes of Recordable Continuous Shooting

    Approx. 60 min.

    Dimensions and Weight

    Dimensions (W x H x D)

    112.6 x 69.9 x 45.3 mm / 4.4 x 2.8 x 1.8 in.

    Weight

    427 g / 15.1 oz.(including battery and SD card), 375 g / 13.2 oz. (Camera body only)

    Operating Environment

    Operating Temperature

    32 – 104 °F / 0 – +40 °C

    Operating Humidity

    85 % or less (non-condensing)

    Supplied Accessories

    • Li-ion Battery Pack BP-51
    • Strap
    • STRAP HOLDER SH-11
    • USB AC ADAPTER UAC-21
    • USB CABLE (C-C) SUC-41
    • HOT SHOE UNIT HU-11
    • Body Cap
    • Instruction Manual
    • Limited Warranty
    • Warranty Sticker

    Optional Accessories

    • HAND GRIP HG-11
    • LARGE HAND GRIP HG-21
    • LCD VIEWFINDER LVF-11
    • ELECTRONIC VIEWFINDER EVF-11
    • BASE PLATE BPL-11
    • CABLE RELEASE CR-41
    • BASE GRIP BG-11
    • DC CONNECTOR CN-21
    • BATTERY CHARGER BC-71
    • AC ADAPTER SAC-7P
    • STRAP HOLDER SH-11 (2pcs)

    Product Lineup

    fp L

    • Body

      Barcode No.
      00-85126-93903-8
    • fp L + ELECTRONIC VIEWFINDER EVF-11

      Barcode No.
      00-85126-93907-6

    FAQ

    Accessories

    Supplied Accessories

    LI-ION BATTERY BP-51

    This dedicated battery is included as standard equipment for the SIGMA fp series and SIGMA dp Quattro series.

    Barcode No.
    00-85126-93039-4

    CONVERTER CAP LCT-Ⅱ TL

    This is a dedicated body cap for SIGMA fp series.

    Barcode No.
    00-85126-93732-4

    NECK STRAP FOR fp

    This is a dedicated neck strap for SIGMA fp series.

    Barcode No.
    00-85126-93760-7

    STRAP HOLDER SH-11 (2 pcs.)

    This is a dedicated strap holder for SIGMA fp series. It will be sold as a set of two.

    Barcode No.
    00-85126-93840-6

    HOT SHOE UNIT HU-11

    A removable hot shoe unit with a mechanism to prevent HDMI cable from coming off.

    USB AC ADAPTER UAC-21

    This is an AC adapter supplied with the SIGMA fp L.

    USB CABLE SUC-41

    This is an USB cable supplied with the SIGMA fp L.

    Separately Sold Accessories

    HAND GRIP HG-11

    A grip designed exclusively for the SIGMA fp series for an improved hold.

    Barcode No.
    00-85126-93733-1

    LARGE HAND GRIP HG-21

    A large grip that further enhances a secure hold, designed exclusively for the SIGMA fp series.

    Barcode No.
    00-85126-93734-8

    LCD VIEWFINDER LVF-11

    A viewfinder designed exclusively for use with the SIGMA fp series. Mounted over the LCD monitor, it cuts out extraneous light. It has a diopter adjustment of −2 to +1 dpt. With a 2.5x* magnification, it helps photographers to check focus and compose their shots. The specially designed, high-performance lens and advanced lens coating secure excellent visibility.
    * The value of magnification was determined based on a definition commonly used for calculating the power of a magnifying glass.
    * SIGMA BASE PLATE BPL-11 Supplied.

    Barcode No.
    00-85126-93735-5

    ELECTRONIC VIEWFINDER EVF-11

    An external electronic viewfinder(optional) designed exclusively for use with the SIGMA fp series. With its 0.5 inch, 3.68 M dots OLED panel, this high-resolution, high-luminance viewfinder will make you feel immersed in your photography experience more thoroughly than ever.
    *The EVF-11 and the HU-11 cannot be mounted on the camera together.

    Supplied Accessories

    EYECUP EC-31, LARGE EYECUP EC-41, Semi-hard Case VC-07A

    Barcode No.
    00-85126-93904-5

    BASE PLATE BPL-11

    A base plate designed exclusively for the SIGMA fp series. In addition to mounting an LCD VIEWFINDER LVF-11 to the body, it can also be utilized to attach standard accessories commonly used for video shooting by using 3/8-inch threads.
    * Supplied with the LCD viewfinder (LVF-11).

    Barcode No.
    00-85126-93736-2

    CABLE RELEASE CR-41

    A cable release designed exclusively for the SIGMA fp series. It comes with a φ3.5mm stereo mini plug to connect the microphone.

    Barcode No.
    00-85126-93737-9

    BASE GRIP BG-11

    When it is attached to the screw hole on the bottom surface of the camera, it allows handgrip-style of shooting. It is compact and convenient and therefore very easy to carry. The bottom part of the Base Grip BG-11 has a screw hole so that it can attach directly to a tripod.

    Barcode No.
    00-85126-93144-5

    DC CONNECTOR CN-21

    A connector that connects the SIGMA fp series to an AC adapter or external power supply source.
    * Supplied with the dedicated AC adapter “AC ADAPTER SAC-7P”.

    Barcode No.
    00-85126-93738-6

    BATTERY CHARGER BC-71

    A battery charger set designed exclusively for the SIGMA fp series’ battery BP-51.

    Barcode No.
    00-85126-93740-9

    AC ADAPTER SAC-7P

    A dedicated adapter for using SIGMA fp series with a household power supply. Recommended for long-time shooting, image playback, etc.
    Includes DC connector SIGMA DC CONNECTOR CN-21.

    Barcode No.
    00-85126-93748-5

    ELECTRONIC FLASH EF-630

    The high-power EF-630 flash enables TTL automatic flash metering. It has wireless flash connectivity and a high-speed synchronization function that can be used at high shutter speeds, giving photographers further scope for creative expression.

    MOUNT CONVERTER MC-21

    The SIGMA MOUNT CONVERTER MC-21 allows SIGMA SA mount and SIGMA’s CANON EF mount interchangeable lens owners to use their lens investment on L-Mount camera bodies.

    MOUNT CONVERTER MC-31

    The new MOUNT CONVERTER MC-31 allows you to use your PL mount interchangeable lenses with the L-Mount camera body, such as SIGMA fp / SIGMA fp L.

    Supplied Accessories

    Cap, Support foot, Hex wrench, Screwdriver,
    Mount lock screw, L-Mount shim

    Barcode No.
    00-85126-93819-2
